Douglas DC-9 aircraft rigged to a test bench with key scalar variables used to define the geometry. This focus is to only change scalars that define the wing’s geometry and observe the effect on the entire aircraft. Changing one of the scalar values, the other scalars are adjusted based on a set of equations in the component. The wing’s mass changes with geometry.
